Price: -
Parameter:
-
LED : KW CSLNM1.TG
-
FLUX: 400lm max
-
Mode: 12groups ,Max current output 0.5A (AA battery),Max current output 1.5A (14500 lithium battery),
-
Mode memory: yes
-
Maximum efficiency: 90%(13groups)
-
Battery: 1 * AA / 14500 (not included)
-
Lighting range: 50-100meters
-
Material: Ti
-
Waterproof grade: IPX4
-
Switch type: reverse
-
Reflector type: smooth
-
Lens : normal glass
-
Size: 21mm(diameter) ,96.8mm(length)
-
Weight:78g (only flashlight ,not include the clip/lanyard/package)
-
Accessory: 1*clip,1*lanyard
12groups
if flashlight is turned on,tap the switch 20 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and “tap the switch in the flashing process” means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
————-sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (1%、10%、30%、100%)
————-sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (1% 10%、35%、100%、strobe、biking、batcheck)
————-sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%、35%、10%、1%)
————-sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1% 20%、100%、strobe、biking、batcheck)
————-sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%、20%、100%)
————-sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%、20%、1%)
————-sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (1% 10%、50%、strobe、biking、batcheck)
————-sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(1%、10%、50%)
————-sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%、10%、1%)
————-sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (20%、100%)
————-sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%、20%、strobe)
————-sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100%)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
battery-check instructions:
<2.95V 1 flash,
2.95-3.25V 2 flashes,
3.25-3.55V 3 flashes,
3.55-3.85V 4 flashes,
>3.85V 5 flashes
Notice that there is no battery-check function if flashlight is powered by the 1.5V battery
