Single Phase Energy Meter Din Rail Wattmeter Voltmeter Ammeter Power Meter AC 40-300V 0-100A Energy Voltage Current Meter

Single Phase Energy Meter Din Rail Wattmeter Voltmeter Ammeter Power Meter AC 40-300V 0-100A Energy Voltage Current Meter

Specification:

Accuracy: 1%±2 words

Installation: Din-Rail

Range: AC voltage: AC 40.0-300.0V

AC Current: AC 0-100.0A, the current resolution is 0.01A

Frequence: 45.0Hz-65.0Hz

Power Facter: 0.00-1.00PF

Electric Power: 0-450000W, resolution is 0.1W when 0-9999.9W, the rest is 1W

Electric Energy: 0-9999kwh, resolution is 0.01kwh when 0-999 99kwh, 0.1kwh when 1000-99999 .9kwh, 1kwh when larger than 999.9kwh

Note:

1. Due to the light and screen difference, the item's color may be slightly different from the pictures.

2. Please allow 1-3cm differences due to manual measurement.

Package Included:

1x Energy Meter
