HT-190/191/192 Laser Distance Meter laser range finder scope
Introduction to the product This series product is a type of multiple-function laser distance meter that may measure distance, area and volume. The product has the characteristics of beautiful appearance, simple operation and high measurement accuracy and is the laser distance meter geared to professional users. Application fields: widely used in the fields of electricity, water conservancy, communication, environment, buildings, geology, police affairs, fire fighting, blasting, navigation, railways, military science, agriculture, forestry, real estate and outdoor sports, etc.
Specifications:
|
Model Number
|
HT-190
|
HT-191
|
HT-192
|
||
|
Measurement range
|
0.05～50M
|
0.05～70M
|
0.05～100M
|
||
|
Weight
|
116g (battery not included)
|
100g (battery not included)
|
|
||
|
Size
|
112.3mm×51.6mm×28.8mm
|
|
|
||
|
Measurement accuracy
|
±(3.0mm+5*10-5*D)
|
|
|
||
|
Measurement unit
|
Feet, inch and meter
|
|
|
||
|
Laser grade
|
Grade Ⅱ
|
|
|
||
|
Laser parameters
|
620-670nm,<1mW
|
|
|
||
|
Continuous measurement
|
√
|
|
|
||
|
Addition/subtraction measurement
|
√
|
|
|
||
|
Area/volume measurement
|
√
|
|
|
||
|
Measurement with Pythagorean Theorem
|
√
|
|
|
||
|
Maximum/minimum value measurement
|
√
|
|
|
||
|
Angle measurement
|
√
|
|
|
||
|
Historical measurement record
|
√
|
|
|
||
|
Setting-out function
|
√
|
|
|
||
|
Calibration function
|
√
|
|
|
||
|
Multiline display
|
√
|
|
|
||
|
Buzzing prompt
|
√
|
|
|
||
|
Operation temperature
|
0~40℃
|
|
|
||
|
Storage temperature
|
-20~60℃
|
|
|
||
|
Power supply
|
2 AAA. 1.5V alkaline batteries
|
|
|
||
|
Laser automatic off
|
1 minute
|
|
|
||
|
Automatic power off
|
3 minutes
|
|
|
||
|
Size
|
112.3mm×51.6mm×28.8mm
|
|
|
||
